WEDO Beryllium Copper Chisel Non Sparking Drift Cylindrical Chisel Bam/FM/GS Certified
WEDO TOOLS CO.,LTD- Punch Type：Drift Cylindrical Chisel
- Material：Beryllium Copper
- Color：Golden Yellow
- Customized：Customized
- Condition：New
- Transport Package：Plastic Bag,Box,Carton,Pallet
Base Info
- Model NO.：BE223B
- Trademark：WEDO
- Origin：China
- HS Code：8203400000
- Production Capacity：30000 Piece Per Year
Description
SIZE Beryllium Copper Φ(inch) Φ(mm) L(mm) N.W.(g) BE223B-1002 3 9 110 20 BE223B-1004 4 10 110 57 BE223B-1006 6 12 115 105 BE223B-1008 8 14 120 130 BE223B-1010 10 16 145 200 BE223B-1012 12 18 160 280 BE223B-1014 14 20 180 410 BE223B-1016 16 24 200 640 BE223B-1018 18 30 225 1070 BE223B-1020 20 32 225 1230
Aluminum Bronze Non-sparking Tools
1. Appropriate for operation with ethylene concentration below 7.8%
2. Surface Color: Silver Yellow
3. Micro-magnetic
4. Hardness: 20-30 HRC
5. Tensile Strength: 782N/mm²-989N/mm²
6. Elasticity Limit: 450N/mm²-550N/mm²
7. Extensibility: δ≥5%
Beryllium Copper Non-sparking Tools
1. Appropriate for operation with hydrogen concentration below 21%,
2. Surface Color:Golden Yellow
3. Non-magnetic
4. Hardness: 30-40 HRC
5. Tensile Strength: 1117N/mm²-1326N/mm²
6. Elasticity Limit: 840N/mm²-880N/mm²
7. Extensibility: δ≤1.0%
To ensure the explosion-proof performance, after the raw materials are melt with scientific ratio, QC personnel will take sample piece to do drop weight and friction test according to GB/T 10686-2013 standard. The test is conducted under the highest level ExIIC, hydrogen concentration 21%. Only if the samples are tested qualified can the next step of production be carried out.
The explosion-proof performance of WEDO non-sparking tools is guaranteed for lifetime.
DETAILS AND APPLICATION
Aluminum Bronze Non-sparking Tools
1. Appropriate for operation with ethylene concentration below 7.8%
2. Surface Color: Silver Yellow
3. Micro-magnetic
4. Hardness: 20-30 HRC
5. Tensile Strength: 782N/mm²-989N/mm²
6. Elasticity Limit: 450N/mm²-550N/mm²
7. Extensibility: δ≥5%
Beryllium Copper Non-sparking Tools
1. Appropriate for operation with hydrogen concentration below 21%,
2. Surface Color:Golden Yellow
3. Non-magnetic
4. Hardness: 30-40 HRC
5. Tensile Strength: 1117N/mm²-1326N/mm²
6. Elasticity Limit: 840N/mm²-880N/mm²
7. Extensibility: δ≤1.0%
To ensure the explosion-proof performance, after the raw materials are melt with scientific ratio, QC personnel will take sample piece to do drop weight and friction test according to GB/T 10686-2013 standard. The test is conducted under the highest level ExIIC, hydrogen concentration 21%. Only if the samples are tested qualified can the next step of production be carried out.
The explosion-proof performance of WEDO non-sparking tools is guaranteed for lifetime.
